产品功能/Product function:

         额定电压/RatedVoltage:AC6kV--6.6kV

         额定频率/Rated Frequency:50Hz--60Hz

         额定电流/Rated Current:700A

         电缆根数/Cable Quantity:1-2根

         防护等级/Degree of Protection:IP56

         恒张力自动控制，手/自动收放电缆

         constant tension automatic control, hand/automatic cable retraction

         环境温度/Ambient temperature:﹣30℃--﹢50℃

         相对湿度/Relative humidity:＜95％

         海拔高度/Altitude:≤1000m

应用标准/Applied standards:

         Classification:DNV,BV,ABS,LR,CCS,RINA etc.

         Type approved:ABS and CCS

         IEC/ISO/IEEE80005-1 2022

         IEC62271-200

主要特点/Main Features:

       Power up to 7.5MVA at 6.6kV 60Hz(在6.6kV 60Hz时，功率可达7.5MVA)

       Slip ring up to 700A(滑环高达700A)

       Magnetic coupling, non-contact,friction-free,lubrication-free(磁耦合，无接触，无摩擦，无润滑)

       Automatic tension control(自控张力控制)

       Double roller chain(双滚子链)

       Maintenance(维护方便)

防风雨外壳Weatherproof Housing(Optional):

       Physically protected against heavy seas and mechanical damages(物理保护以抵御海浪和机械保护)

       Dehumidifying/Heating(除湿/加热)
